Maximum sleeve bearing loads |
|
Axial(dynamic) |
1.0 N |
|
Radial(4mm from jamming ring) |
2.7 N |
 |
Press-fit force(static) |
80 N |
 |
Axial play(measured under less than 4N axial force) |
0.05->0.15mm |
 |
Maximum radial play |
0.02mm |
 |
L:Maximum allowable screw depth into flange 3.5mm |
 |
Motor data tested at ambient temperature 25 .Data varies when the temperature changes. |
 |
Operation outside stated limits may affect motor service life.Please consult us before doing so. |
 |
Motor service life depends on operating conditions.Under normal conditions, service life of 1000 to 3000 is achievable. |
 |
Electrical connection: 2 wire pigtail approx. 150 mm long. |
